The Riot Functional Trainer – Versatile 4-Point Cable Training System

The Riot Functional Trainer is a heavy-duty 4-point cable training system designed to deliver maximum versatility in modern strength training environments. Built around the same structural dimensions as the Riot MRR rack system, it can function either as a standalone cable machine or as a fully integrated module inside a Riot MRR rack or Riot MRR rig setup.

This modular approach allows gym owners and athletes to combine traditional barbell training with advanced cable training in a single station, creating a compact and extremely versatile strength training solution. Whether used in commercial gyms, strength facilities, X-Fit boxes or high-end home gyms, the Riot Functional Trainer enables a wide range of functional exercises, isolation work and full-body cable training.

The system is built with four independent cable pull points, offering exceptional training flexibility. Two adjustable cable trolleys allow users to position the cables at multiple heights, making movements such as cable crossovers, flyes, curls, triceps pushdowns, face pulls and rotational core work possible. In addition to the adjustable pulleys, the machine includes two dedicated lat pulldown stations and two low row stations, enabling multiple exercises to be performed simultaneously.

Each pulley rotates freely, allowing 360° movement in any training plane. This makes the machine particularly effective for functional strength training, athletic conditioning and movement-based exercises where natural movement patterns are essential.

A key feature of the Riot Functional Trainer is the 2:1 pulley ratio used on all cable pull points. Compared with traditional 1:1 cable systems, the 2:1 ratio provides longer cable travel and a significantly smoother resistance curve. The reduced inertia and improved resistance control make exercises feel more fluid and precise, which is especially beneficial for controlled hypertrophy training and technical movements.

The system uses two independent weight stacks of 120 kg each, with 5 kg increments. This allows athletes to adjust resistance accurately and makes the station suitable for users of different strength levels. For facilities that require higher loading capacity, the stacks can be upgraded with optional +30 kg extensions to make them 150kg.

The frame design of the Functional Trainer has been carefully engineered to work seamlessly within rack environments. The weight stack system is offset within the frame, creating additional space inside the station. This allows a bench to be rolled into position easily and ensures that barbell exercises such as squats can still be performed in the rack without interference from the cable system.

The Riot Functional Trainer is constructed for heavy daily use. The frame is built from mild steel with 75 × 75 × 3 mm uprights, providing the structural rigidity required in professional training environments. High-quality aluminium pulleys and stainless-steel guide rails ensure smooth cable movement and long-term durability, while the cast-iron weight stacks deliver consistent resistance over years of training.

The system also includes an integrated footplate for comfortable positioning during seated rowing movements. An optional leg and hip roller attachment can be added to support athletes during heavy lat pulldown exercises. This attachment can also be used on compatible racks for movements such as hip thrusts or split squats, further expanding the exercise possibilities.

Setup Name	Mounting Type	Required Components	Stability Method	Notes / Use Case
Wall-Backed Freestanding Setup	Freestanding against wall	Front long feet mandatory (included)	Front stabilisation via extended feet, rear supported by wall	Space-efficient solution using wall as rear support
Fully Freestanding Setup	Freestanding independent	Front + rear feet mandatory (included)	Full base stabilisation front and back	Complete standalone solution
Wall-Mounted Setup Top-Braced	Wall-mounted	2 × 275 mm crossmembers, top only, mandatory (included)	Fixed to wall with upper structural bracing	Minimal footprint, clean installation
Rack-Mounted Setup 2100 Height	Rack-integrated MRR	Compatible rack, 2100 height. Choose your depth: 425 / 725 / 1075	Mounted directly to rack uprights	Integrated cable system for MRR racks
Rack-Mounted Setup 2300 Height	Rack-integrated MRR	Compatible rack, 2300 height. Choose your depth: 425 / 725 / 1075	Mounted directly to rack uprights	Integrated cable system for MRR racks

EXERCISE VARIETY

Because of its modular design and multi-station setup, the Riot Functional Trainer supports an extremely wide range of exercises including:

Lat pulldowns
Seated cable rows
Cable crossovers and chest flyes
Triceps pushdowns
Biceps curls
Face pulls
Core rotations and woodchoppers
Cable lunges and lower body work
Functional athletic movements and conditioning drills

The combination of modular rack integration, dual weight stacks, smooth pulley mechanics and four independent cable stations makes the Riot Functional Trainer a powerful addition to any strength training facility.

Please note: handles not included!
